Chassis No

SF2020G

Engine model

Forced circulation cooling system

Total mass

(kg)3495

Engine displacement

(L)1.595

Overall dimension

5600*1750*2900 V*B*H(mm)

Rated power

(kw)22

Wheel base

(mm)2800

Max standard turning rate

(r/min)3200

epipodium

(mm)1000

Mixing geometric volume

(m³)3.9

Rear overhang

(mm)1800

Maximum  mixing volume

(m³)2

Gradeability

25

Feeding speed

(m³)≥0.5

Max travel speed

(km/h)≤50

Discharge speed

(m³)≥0.8

Min turning diameter

(m)≤15

Max rotate speed

(r/min)6-10

clutch

Dry biplate joints

Mixing drum dip

(°)16

Transmission type

Belt drive

Max diameter of mixing drum

(mm)1560

Drive mode

Rear wheel drive

Reduction box

HJ20043

Steering mode

Steering wheel mode

Oil hydraulic pump

32 gear pump

Brake

Single channel rear brake

Hydraulic motor

Gerotor motor

Parking braking

Mechanical rear wheel brake

Water tank capacity

(L)180

Tyre

700-16

Water supply form

Air pressure water

Advantages

Big mixing drum geometry amounts,sufficient amounts transpot.

Small volume of carload,big horse power,fast speed of feeding

and discharging.

tank vanes discharge spout adopts high strength,wear-resisting

Low alloy material,improved the service lift of carload greatly.

washing convenient.

easy handiness,two sides of cab controls.

rational design of feeding and discharging system :it adopts circulation design ,assured feeding and discharging fluently,no leakage.
