- Size: 36
- Place of Origin: China
- Brand Name: Sitong truck crane
- Model Number: STSQ3D
- Weight: 3530.000 kg
- :
- :
Product model | STSQ3D |
Total mass kg | 3530 |
Overall dimension mm | 5300*1500*2200mm |
Rated elevating capacity kg | 3000 |
Max Lifting Moment KN.M | 95 |
Max. Lifting Height m | 15m(3.5m per boom*7 sections) |
Main hook single load kg | 3000 |
Main hook single elevating speed m/min | 55 |
Engine model | ZS1115 |
Tires | 8.25-16LT rear tire,6.00-14LT front tire |
Braking form | Mechanical |
Steering form | The steering wheel circulation ball type |
Crane jib structure | Hexagon |
Main Lifting Mechanism | Category two planet wheel with a brake inside |
Auxiliary Lifting Mechanism | Category one gear brake motor |
Swing Bearing | QWA800.25A 50MN |
Vertical hydraulic leg | HSG110/60-400 |
Horizontal hydraulic leg | Manual |
Platform | High strength |
Dynamic Motor | BM3-400 |
Crane Cab | Tailor-made |
Crane Start | Tailor-made |
Throttle | Hydraulic |
Warning Horn | Mono snail |
Pressure gauge and switch | Shockproof component |
Shrinkable frame | 1.0m shrinkable frame for excellent lifting performance |
