Quick Details
Place of Origin: Shandong, China (Mainland)
Brand Name: LUYING
Model Number: STW18
After-sales Service Provided: Engineers available to service machinery overseas
Color: Yellow
Verified Supplier
Jining Sitong Construction Machinery CO.,LTD
| Factory
Experience:2003-01-01
Buyer Protection
- Guaranteed Secure Payments on Every Order
- Refund if your item is not delivered or as described
- Buyer Protection after order confirmation
Latest Browsing
Product Details
- Place of Origin: Shan dong
- Brand Name: Sitong truck crane
- Model Number: STW18
Packaging & Delivery
Packaging Details: Standard Export Packing Delivery Detail: 15 days after receiving down payment
- Place of Origin: Shan dong
- Brand Name: Sitong truck crane
- Model Number: STW18
Parameters | Unit |
Overall dimension: L*W*H(mm) | 2500×990-1320×2560 |
Track Gauge (mm) | 760--1090 |
Overall length of track (mm) | 1588 |
Curb weight (KG) | 1800 |
Engine Model | 403D-11 |
Rated Power (KW) | 14.7KW/2200rpm |
Fuel consumption rate (g/kw.h) | 196 |
Rated bucket capacity (cbm) | 0.05 |
Max digging depth (mm) | 2118 |
Max digging diameter (mm) | 3888 |
Max digging height (mm) | 3315 |
Max dumping height (mm) | 2315 |
Rotation angle of table | 360° |
Rotation angle of working devices | 180° |
Working pressure of hydraulic system (mpa) | 20 |
Rated flow of hydraulic system (L/min) | 48.4 |
Travelling speed (Low) (KM/h) | 2.79 |
Travelling speed (High) (KM/h) | 5.29 |
Gradeability at low speed | 37° |
